We specialize is offering unique products and services for the
embedded electronics industry. We develop, design and manufacturer hardware
solutions for a variety of applications, including Flash memory devices (NOR
and NAND types), SPI programmable devices, JTAG applications, USB hardware development,
wireless communication stacks, and end-user
January 4th, 2022: A new year of doing what we love! Thanks to everyone who has helped support us over the years. A new LabVIEW plugin for FlashcatUSB is now available to all commercial license holders. This plugin can be used to integrate automated programming into your lab or production lines. You can download it now in the software section.|
October 20th, 2021: Due to the global chip shortage and other supply restrictions, we are implementing a one-unit limit on FlashcatUSB Professional and MACH1 per buyer every 30 days. Thank you for your understanding.
March 19th, 2021: Software has been upgraded to build 622. Automatic firmware updating has been added to XPORT and Classic models. Notice: we are going on vacation from March 22nd to 29th. Orders placed during this time will ship in the order they are received when we return.
December 25th, 2020: Software has been upgraded to build 615. In addition to the usual updates, a new console version is now available with binaries compiled for Windows and source code that is cross-platform compatible with Linux using the .NET 5.0 Framework.
July 16th, 2020: End of Life Announcement: The software has been updated to Build 603. This will be the last one to officially support FlashcatUSB Professional (PCB 4.0) and XPORT PCB 1.x. Moving forward, all the releases will only support:
FlashcatUSB Classic U2 (PCB 2.0-2.2)
FlashcatUSB Classic U4 (PCB 3.0)
FlashcatUSB Professional (PCB 5.x)
FlashcatUSB MACH1 PCB (2.x)
FlashcatUSB XPORT PCB (2.x)
April 9th, 2020: Advanced JTAG modules for ARM systems is currently in development, as well as support for eMMC devices for MACH1, these will be available to all commercial license holders. Supply chain issues have been resolved and all sockets are in stock. I apologize for any delays this may have called. For University researchers, I am now available for conferences (Sept. earliest) and collaboration projects, please contact me for scheduling.
January 15th, 2020: FlashcatUSB Professional PCB 5.0 is now in stock and shipping! This major hardware update replaces the CPLD with an ultra-small FPGA with up to 4000 logic elements. In addition to over twice the performance of PCB 4.x, the new design can update logic in real-time, which now eliminates the the delay when changing device modes. (FlashcatUSB Professional)
June 22nd, 2019: XPORT PCB 2.0 is now shipping. In addition, all parallel sockets have been updated to use the newer 56-pin connector system. Sockets for older PCB 1.x will still be available via request.
May 9th, 2019: Cypress Semper Flash support has officially been added to FlashcatUSB Professional. Mach1
now supports SPI protocol and Parallel NOR memories.
February 17th, 2019: FlashcatUSB Mach¹ PCB 2.0 is now shipping. Performance is now
more than 5MB/s (screenshot) for a typical X8 device. Software has been updated and FlashcatUSB Pro now supports JTAG boundary scan programming for directly connected parallel NOR Flash devices.
January 20th, 2019: FlashcatUSB Mach¹ PCB 2.0 is now in production and will be shipping soon in limited quantities. This new version has been
redesigned to be even higher performance and now uses a FPGA design. If you have an older PCB 1.0, please contact us immediately to arrange an exchange.
November 22nd, 2018: Cypress HyperFlash devices (S26KL/KS) are now officially supported by Mach¹. FlashcatUSB Software BETA is available for download. New features include Microchip one-wire devices and real-time buffer editing feature (Screenshot). See the documentation folder for more information.
August 9th, 2018: We now offer a wide range of BGA sockets. For SPI, we now have in stock BGA-24 devices. For parallel devices, we have BGA-64 (11x9mm, and 9x9mm), as well as BGA-63 for SLC NAND devices. Quantities are limited, contact us if you need a lead-time quote. Software has been improved and is now at Build 545. Mach¹ production and development is currently our highest priority and a new firmware update is coming soon.
May 20th, 2018: The software has been updated to build 538. Additional support and changes for PCB 4.0 have been added, including support for I2C devices (BETA). Also I am pleased to announce and the Mach¹ is now in the final production stages and we will be shipping first run boards to early backers of the project this week!
May 8th, 2018: FlashcatUSB Professional has been upgraded to PCB 4.0. We redesigned the hardware to use a high-speed (480Mbps) USB interface in combination with an in-circuit programmable CPLD for maximum speed and utility. If you have an older 3.x board, please contact us to take advantage of our trade in program. The software has also been updated to build 533 and includes many new updates to our NAND engine.
March 8th, 2018: A FlashcatUSB software has been upgraded to include a ton of new features. OTP EPROM devices has been added to support various PLCC-32 and DIP-32 devices. The language file has been updated to include Italian and Chinese. JTAG support has been added to Professional. The Flash library has been updated. And Winbond W25M121AV (NOR and NAND) has been added (see image).
January 19th, 2018: A new major software update has been posted. This version (Build 514) adds many new features, including updated multi-language support, and support for ECC for SLC NAND devices. The software can now be configured to automatically load ECC data and auto-correct data on the read operation, as well as generate ECC data and write it during a program operation.
December 5th, 2017: FlashcatUSB Software (Build 501) is now available for download. This version adds updated SPI-NAND support, additional SLC NAND options, and better read/write support. New firmware is also included and must be installed prior. This release supports Classic, Professional and XPORT hardware platforms.
November 19th, 2017: FlashcatUSB PCB 2.2 giveaway! We are currently re-updating the language files of the FlashcatUSB software and are asking for translations. As a special reward, we are sending new FlashcatUSB Classic (PCB 2.2), including shipping, to each contributor.
November 8th, 2017: The software has been updated to support SPI NAND devices for both FlashcatUSB Classic and Professional. Serial NAND devices from Micron and GigaDevice are supported up to 4Gbit, which includes the MT29FxG01A and GD5F product lines. In addition, lots of other SPI devices have been added, as well as many software fixes.
October 13th, 2017: The FlashcatUSB software, script engine, and other modules have finally been merged into a single code tree for both Classic and Professional applications. This means the software for both hardware will be distributed together from now on and a update in one will also update the other. The newest software release is now available for download and includes new AVR firmware for Classic, new USB drivers, updated SPI database, and the JTAG engine (including TAP state-machine) is now accessible via the script engine (see included documenation). Head over to the Software page to download the newest version!
September 24th, 2017: Major BETA updates are now available. This includes major changes/update to both the Classic and Professional software. Updates include the Flash database, the Extension Port engine, and a new Multi-device mode has been added (see screenshot), which will allow high-volume/production use of the hardware. And finally enclosures/cases for FlashcatUSB Professional are now in stock and will be included with every order.
August 21st, 2017: FlashcatUSB xPort is
now available. This FlashcatUSB product is based on the Classic design which incorporates the extension port into a single chip solution that is low-cost and twice the performance. In addition, the Classic (Build 462) and Professional (Build 145) software has been updated. Support for Spansion's Write-to-Buffer (screenshot) has been added and A24(Extension Port)/A26(xPort) address support has been added to the EXTIO mode.
June 18th, 2017: New software updates for FlashcatUSB Classic (build 446) and Professional (build 130) have been posted.
June 4th, 2017: New BETA software updates for FlashcatUSB Classic and Professional are ready. Extension port transfer speed has been increased by more than 25%. The NAND engine has been updated, and a new tool (Block Manager) has been added to allow real-time interactation with the block map feature. Download Build 445 (FCUSB Classic). Download Build 125 (Professional).
May 17th, 2017: FlashcatUSB build 434 has been posted.
Download here. Changes include all of the updates from the BETA and 25% increase in NAND read/write performance. In addition, FlashcatUSB Professional Build 120 BETA has been posted as well.
Download here. Support for the Extension Port (NOR X8, X16 and NAND) has been added.
April 20th, 2017: FlashcatUSB BETA software build 430 is now available. This version includes a new updated firmware (4.18). And includes over a dozen new changes, updated Flash SPI database (over 20 new ISSI devices added), and the software has better quad I/O support. With this version, you can now connect to a SPI flash in quad mode and be able to perform read/write operations. In addition, the interface has been upgraded to now support device-specific configurations (if available) for select SPI devices (see screenshot). If you have a SPI with non-vol settings that you need to use, contact us to add support. And finally, a major
FlashcatUSB Professional software update is going to be posted within a few days. We are currently busy testing the new library and functions with the thousands of Flash devices we currently support.
March 19th, 2017: FlashcatUSB Professional (PCB 3.0) is now available. Quantities are limited. SO-44 Adapters for the Extension port have been revised and now include an on board charge pump to supply VPP with up to 12v (required for some Flashes). The DIP32 adapters is now available as well.
January 16th, 2017: FlashcatUSB build 406 BETA is now available for download. A new firmware version (4.13) is included. The Flash database has been updated, new flash writing timing feature has been added, and the Flash writing tab has been updated.
December 20th, 2016: FlashcatUSB build 404 and firmware version 4.12 BETA is now available for download. Includes updated NAND engine, and SPI flash database.
FlashcatUSB Professional is now available for pre-order, this new PCB 3.x version includes over 10 times the performance of the previous generation.
November 20th, 2016: FlashcatUSB build 400 and firmware version 4.12 BETA is now available. This version includes the new upgraded NAND engine that supports all of the newly added NAND flash devices. In addition, the software buffer has been changed to allow files to be read and written to via a stream, instead of coping the entire file to memory prior to performing a read or write operation.
November 11th, 2016: WSON-8 SPI sockets are now available as well as TSOP-48 adapters for NAND type
November 10th, 2016: FlashcatUSB build 380 BETA with new AVR firmware (4.07) is ready for download. This version (which is mostly for BETA users) adds support for the PLCC-32 and TSOP-48 socket adapters, and also adds over a dozen new SPI Flash memory devices.
November 6th, 2016: FlashcatUSB Software version 392 is available for
download. Updated several bugs that have been reported. Also added Nordic nRF24LU1+ device support. AVR firmware has been updated to 4.10.
October 16th, 2016: FlashcatUSB Software version 390 is available for download This version features a new upgraded AVR firmware (4.09) that adds full support for the Extension Port and adapters. The new NAND Flash feature (screenshot) allows full programming of NAND Flash memory via the TSOP-48 Type-B socket. SPI database has been upgraded, and the Micron N25Q512 device support has been fixed.
July 20th, 2016: A new update is ready for download. Software build 371 includes many updates for the SPI engine, including adding the ability to switch between page and extended page options for Atmel / Adesto series 45 devices. See screenshot.
July 18th, 2016: The FlashcatUSB Extension Port is now in production. This new add-on device adds support for CFI / parallel memory devices (PLCC-32, TSOP-48, TSOP-56, etc.) directly without using JTAG.
May 22nd, 2016: Software has been updated to build 370. Changes include support for I2C devices with 8bit addressing, additional SPI EEPROMS added, script engine updated, better device compatibility, and more. Download Now. New arrival: DIP8 socket (version 2) now in stock, this version includes support for both SPI and I2C devices!
March 22nd, 2016: A new software update is available for download. Build 368 includes updated Flash database, JTAG support for Lattice CPLD, updated SVF Player, script engine fixes, and more.
February 2nd, 2016: Software version 365 and source code are now available for download. Software now includes support for SQI devices.New arrival: 1.8v SPI adapters are now in stock (purchase here).
January 16th, 2016: Software version 365 is being finished at the moment, it will be available in about 1 week. In addition, the CMOS memory adapter is now available.
November 30th, 2015: Software update (build 362) - includes updated SPI database and now supports CMOS memory (i.e. W49F002U) via a low-cost PLCC32 adapter that we are now producing. If you need this adapter, send us a email so we can get you on the wait-list.
November 1st, 2015: Software update (build 355) - includes Repeat Write Operation feature, as well as adds predefined settings for ST M95xxx series.
October 20th, 2015: Software has been upgraded to RC18 Build 352!
August 25th, 2015: Device has been upgraded to now support I2C EEPROM (see screenshot)!
July 31st, 2015: Software has been updated to RC17, build 350! Lots of new features. Also includes new firmware for PCB 2.x boards.
June 19th, 2015: PCB version 2.1 is in stock and is now shipping! See picture here
May 14th, 2015: SPI test clips are now available for sale. These are wired specifically to work with FCUSB.
April 5th, 2015: Software has been updated to build 345.
Official device programming partner
Our embedded solutions include
circuit board design, manufacture, component
assembly and PCB rework. We offer a wide range of industry standard
technologies including high-pitch surface mount technologies,
including QFN and BGA packages. We
also offer embedded technology consulting for companies that may
want to explore different options available.
Production page for more information)
Our software development services are very efficient, low-cost, and fast. Our
experienced team of programmers can complete your project on time.
We specialize in:
Visual Studio and .NET framework
AVR Studio 7.0 (firmware development)
VB.net and C#.net (software development)
C/C++ (driver development)
PHP / ASP / Python (web applications)
SQL (databases, including MySQL and SQL Server)
(Please see the
Software page for more details)
If you need a quote for a new project, just use the
contact us page.
